6-22 Using DeviceNet Explicit Messaging
and future writes blocked.
• If a marked connection has its EPR value reset to zero (0) after
being marked, then the connection will become unmarked.
Writing to Register Objects Within the DeviceNet to SCANport Communication Module with
Digital Inputs, various register objects buffer I/O in the following
fashion (RO=Read Only, R/PW=Read/Write Protected):
Refer to the “Class Code 0x07 — Register Object” section in
Appendix C, DeviceNet Objects, for more information on the Register
Object.
Instance Access Size Function
1 RO See M-S Out-
put
Poll Response I/O data to controller
2 R/PW See M-S Out-
put
Buffered Poll I/O data from controller
3 RO 32 bits Logic Status & Feedback
4 R/PW 32 bits Datalink A from SCANport Device (if enabled)
5 RO 32 bits Datalink A to SCANport Device (if enabled)
6 R/PW 32 bits Datalink A from SCANport Device (if enabled)
7 RO 32 bits Datalink B to SCANport Device (if enabled)
8 R/PW 32 bits Datalink B from SCANport Device (if enabled)
9 RO 32 bits Datalink C to SCANport Device (if enabled)
10 R/PW 32 bits Datalink C from SCANport Device (if enabled)
11 RO 32 bits Datalink D to SCANport Device (if enabled)
12 R/PW 32 bits Datalink D from SCANport Device (if enabled)
13 RO 32 bits Logic Status and Feedback
14 R/PW 32 bits Logic Command (Last Logic Command is ANDed with the first word
in this command and ORed with the second word in the command.
The reference is not modified. This command allows bit changes to
the logic command without affecting the speed reference or other
control bits.)
