Rockwell Automation 2100-GK61 DeviceNet to SCANport User Manual
Page 31
Publication 2100-UM001B-EN-P – January 2001
Chapter
3
Configuring the DeviceNet to
SCANport Communication Module
with Digital Inputs
Using RSNetWorx for DeviceNet
Chapter Objectives
Chapter 3 provides information that you need to configure the
2100-GK61 module over the DeviceNet network. In this chapter, you
will read about the following:
•
Factory-default settings for the module.
•
RSNetWorx software.
•
Equipment necessary to use RSNetWorx software.
•
Editing the 2100-GK61 adapter’s parameters using RSNetWorx
software.
This section assumes you have experience using RSNetWorx
software to configure a DeviceNet network.
Factory Default Settings for the
2100-GK61
The factory-default settings of the DeviceNet to SCANport
Communication Module with Digital Inputs include the following:
•
16-bit Logic Command/Status enabled for polling.
•
16-bit Reference/Feedback enabled for polling.
•
If the scanner is put into program mode or the network faults, the
SCANport product will be faulted by the module. (Firmware
must be version 2.080 or above. Earlier firmware versions are
flash upgradeable. Consult the factory.)
•
A node address of 63.
•
DeviceNet autobaud detection enabled.
