Publication 2100-UM001B-EN-P – January 2001
C-16 DeviceNet Objects
Class Code 0x10 — Parameter
Group Object The Parameter Group Object identifies and provides access to groups
of parameters in a device grouping. The Parameter Group Object
provides convenient access to related sets of parameters.
Class Attributes
Instances
The number of instances varies based on the number of groups in the
SCANport product. One additional group is added for the module.
Instance Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
1 Get Parameter
group
version UINT Returns 1.
2 Get Max
Instance UINT Maximum instance
number of an object
currently created in this
class level of the device.
8 Get Native
Language USINT Language ID for all
STRING accesses.
0 = English
1 = French
2 = Spanish (Mexican)
3 = Italian
4 = German
5 = Japanese
6 = Portuguese
Instance Description
1 – (n - 1) SCANport product groups
n ➀ Module group
➀ n is the value returned by a get from class attribute 2 (max instance).
Attribute ID Access Rule Name Data Type Description
1 Get Group Name
String SHORT_
STRING
A human-readable string representing the group
name (e.g., set-up, frequency set).
Maximum number of characters = 16.
2 Get Number of
Members in Group UINT Number of parameters in group.
3 Get 1st Parameter
Number in Group UINT Parameter instance number.
4 Get 2nd Parameter
Number in Group UINT Parameter instance number.
n Get (n-2)th Parameter
Number in Group UINT Parameter instance number.
