Publication 2100-UM001B-EN-P – January 2001
DeviceNet Objects C-7
Instance Attributes
Common Services
Not supported.
Attribute ID Access Rule Name Data Type Description
1 Get State USINT State of the connection as defined in the
DeviceNet specification.
2 Get Instance type USINT Indicates I/O or Messaging connection.
3 Get Transport Class
Trigger USINT The Transport Class Trigger for this
instance.
4 Get Produced Cnxn ID USINT CAN Identifier to transmit on.
5 Get Consumed Cnxn ID USINT CAN Identifier to receive on.
6 Get Initial Comm Char USINT Defines the DeviceNet message groups
that the tx/rx Cnxn’s apply.
7 Get Produced Cnxn Size UINT Max bytes to transmit across this
connection.
8 Get Consumed Cnxn
Size UINT Max bytes to receive across this
connection.
9 Get/Set EPR UINT Expected Packet Rate.
12 Get/Set Watchdog Action USINT How to handle inactivity/watchdog time-
outs.
13 Get Produced Path
Length UINT Number of bytes in the produced
connection path attribute.
14 Get Produced Cnxn Path ARRAY of
USINT
Specifies the application object whose data
is to be produced by this connection.
15 Get Consumed Path
Length UINT Number of bytes in the consumed
connection path attribute.
16 Get Consumed Cnxn
Path ARRAY of
USINT
Specifies the application object to receive
the data consumed by this application.
17 Get/Set Production Inhibit
Time UINT Defines minimum time between new data
production for COS connections.
