Rockwell Automation 2100-GK61 DeviceNet to SCANport User Manual
Page 201
Publication 2100-DU021B-EN-P - January 2004
5-16 Ladder Logic Programming—Including Reading Inputs
SLC Code: SMP-3 output A is turned OFF when Slot 3, Input 0 is true in
Rung 5. SMP-3 output B is turned OFF when Slot 3, Input 1 is true in Rung 6.
In Rung 7, SMP-3 is reset when input 2 of Slot 3 input card is true. Rungs 8
and 9 illustrate how SMP-3 outputs A and B are respectively turned ON when
Inputs 3 and 4 of I/O card in slot 3 are true.
Figure 5.11
