Publication 2100-UM001B-EN-P – January 2001
DeviceNet to SCANport Communication Module with Digital Inputs Parameters B-27
The following table lists possible configurations for the M-S Output
(25) parameter and the types of allocation associated with each
.
M-S Output
ALLOCATION (Number Of Words)
Data Size Sent From The Adapter To The Controller
Poll Only COS Only
Cyclic
Only
Poll &
COS
Poll &
Cyclic
00000 0 NA NA NA NA
00010 3 NA NA NA NA
00100 3 NA NA NA NA
00110 5 NA NA NA NA
01000 3 NA NA NA NA
01010 5 NA NA NA NA
01100 5 NA NA NA NA
01110 7 NA NA NA NA
10000 3 NA NA NA NA
10010 5 NA NA NA NA
10100 5 NA NA NA NA
10110 7 NA NA NA NA
11000 5 NA NA NA NA
11010 7 NA NA NA NA
11100 7 NA NA NA NA
11110 9 NA NA NA NA
00001 3 3 3 3/3 3/3
00011 5 3 3 5/3 5/3
00101 5 3 3 5/3 5/3
00111 7 3 3 7/3 7/3
01011 7 3 3 7/3 7/3
01101 7 3 3 7/3 7/3
01111 9 3 3 9/3 9/3
10001 5 3 3 5/3 5/3
10011 7 3 3 7/3 7/3
10101 7 3 3 7/3 7/3
10111 9 3 3 9/3 9/3
11001 7 3 3 7/3 7/3
