DeviceNet Objects C-25
Class Code 0x67 — PCCC
Object The PCCC Object is used to process encapsulated PCCC messages
from DeviceNet. The PCCC Object does not implement any specific
class or instance attributes, so the instance field for any received
messages is ignored.
Class Attributes
Not supported.
Instance Attributes
Not supported.
Common Services
Not supported.
Object Specific Services
Message Structure for Execute_PCCC
Service Code
Implemented for
Service Name
Class Instance
0x4B No Yes Execute_PCCC
0x4D No Yes Execute_Local_PCCC
Request Response
Name
Data
Type
Description Name
Data
Type
Description
Length USINT Length of requestor ID Length USINT Length of requestor ID
Vendor UINT Vendor number of
requestor Vendor UINT Vendor number of
requestor
Serial Number UDINT ASA serial number of
requestor Serial Number UDINT ASA serial number of
requestor
Other Product
Specific Identifier of user, task, etc.
on the requestor Other Product
Specific Identifier of user, task, etc.
on the requestor
CMD USINT Command byte CMD USINT Command byte
STS USINT 0 STS USINT Status byte
TNSW UINT Transport word TNSW UINT Transport word. Same
value as the request.
FNC USINT Function code. Not used for
all CMD’s. EXT_STS USINT Extended status. Not used
for all CMD’s.
PCCC_params ARRAY of
USINT CMD/FNC specific
parameters PCCC_results ARRAY of
USINT CMD/FNC specific result
data
