Publication 2100-UM001B-EN-P – January 2001
C-4 DeviceNet Objects
Class Code 0x02 — Message
Router Object The Message Router Object provides a messaging connection point
through which a client may address to any object class or instance
residing in the physical devices.
Class Attributes
Not supported.
Instances
Instance Attributes
Common Services
Instance Description
1 Message Router Object
Attribute
ID
Access
Rule
Name
Data
Type
Description
2 Get Number
available UINT Maximum number of
connections supported by the
message router.
3 Get Number
active UINT Number of connections
currently used by system
components.
4 Get Active
connec-
tions ARRAY
of UINT
A list of the connection IDs of
the currently active
connections. This attribute
not used.
Reserved for compatibility
purposes.
Service Code
Implemented for
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
