Publication 2100-UM001B-EN-P – January 2001
Chapter
7
Troubleshooting
Chapter Objectives Chapter 7 provides information about the adapter’s LEDs and basic
troubleshooting procedures. In this chapter, you will read about the
following:
• Locating the LEDs.
• Using the LEDs to troubleshoot the adapter.
LEDs on the 2100-GK61 Module Your communications adapter has three LED status indicators. The
LEDs provide status information about the DeviceNet network,
SCANport connection, and the adapter itself. Refer to Figure 7.1.
Figure 7.1
LED Status Indicators
1
2
3
SCANPort Status
Module Status
DeviceNet Status
Input Status 1-4
