B-20 DeviceNet to SCANport Communication Module with Digital Inputs Parameters
22
Reset Adapter
Ready
Enable
Set Defaults
Ready
Yes
No
Ready = No change or reset.
Enable = Resets the module.
Set Defaults = Sets all parameters to their
factory-default values.
23
Active I/O Cfg
0 or 1 for each
bit
N/A
No
No
Displays what I/O is activated in the adapter.
0 = Off.
1 = On.
24
M-S Input
0 or 1 for each
bit
xxx0, 0001
Yes
Yes
Determines the source of the bits for input.
0 = Peer or other input.
1 = Master-Slave input.
For more information, refer to the “M-S Input
Parameter Configurations” section in this
chapter.
25
M-S Output
0 or 1 for each
bit
xxx0, 0001
Yes
Yes
Determines the source of the bits for output.
0 = Peer or other output.
1 = Master-Slave output.
For more information, refer to the “M-S Output
Parameter Configurations” section in this
chapter.
#
Name
Valid Values/
Settings
Default
Writable
Reset or
Power
Cycle
Description
IMPORTANT:
For information on accessing and editing parameters, refer to Chapter 3, Configuring the DeviceNet to
SCANport Communication Module with Digital Inputs.
xxx0, 0 0 0 0
datalink C
datalink B
datalink A
Cmd/Stat
datalink D
xxx0, 0 0 0 0
datalink D
datalink C
datalink B
datalink A
Cmd/Ref
xxx0, 0 0 0 0
datalink D
datalink C
datalink B
datalink A
Stat/Fdbk
