AT-S62 Management Software Command Line Interface User’s Guide
Section I: Basic Operations 85
SHOW SYSTEM FANCONTROL
Syntax
show system fancontrol
Parameters
None.
Description
Note
This command only applies to the AT-8524POE switch.
This command displays the status of the fan control feature and the
cooling fans in the switch. The fan control feature automatically adjusts the
speed of four of the switch’s five cooling fans based on the ambient
temperature of the room or wiring closet where the unit is installed and the
load requirements of the PoE devices connected to the ports on the unit.
When the feature is disabled, all fans operate at their highest possible
speed. When enabled, fan speed is based on the temperature and the
PoE load requirements. To activate this feature, refer to “SET SYSTEM
FANCONTROL” on page 68.
Figure 8 illustrates the information displayed by this command.
Figure 8. SHOW SYSTEM FANCONTROL Command
The information is defined here:
ˆ Fan Control Mode - The status of the fan control feature. If Off, the
feature is disabled and all fans operate at their highest possible speed.
If On, the feature is activated and the switch adjusts the speed of the
fans, as dictated by the ambient temperature and PoE load
requirements.
Fan Control Mode: Off
Fan#
RPM % Status
-------------------------------------------
1
10700 100 Ok
2 10750 100 Ok
3 10700 100 Ok
4 10700 100 Ok
5 6200 100 Ok
Temperature = 24 C, PoE Current Load = 2.2 Amps (Max. 8.5)
