AT-S62 Management Software Command Line Interface User’s Guide
Section V: Virtual LANs 515
SHOW VLAN
Syntax
show vlan[= name | vid ]
Parameter
vlan Specifies the name or VID of the VLAN.
Description
This command displays the VLANs on the switch. An example of the
information displayed by this command for port-based and tagged VLANs
is shown in Figure 46.
Figure 46. SHOW VLAN Command for Port-based and Tagged VLANs
The information displayed by the command is described here:
ˆ VLAN name - The name of the VLAN.
ˆ VLAN ID - The ID number assigned to the VLAN.
ˆ Protected Ports - The status of protected ports. Since port-based and
tagged VLANs are not protected ports VLANs, this will be No.
ˆ Untagged port(s) - The untagged ports of the VLAN. The untagged
ports are listed as follows.
– Configured: The untagged ports assigned to the VLAN
when the VLAN was created or modified.
– Actual: The current untagged ports of the VLAN. If you
are not using 802.1x port-based network access
control, both the Configured and Actual untagged ports
of a VLAN will always be the same.
VLAN Name ............................ Sales
VLAN ID .............................. 4
Protected Ports ...................... No
Untagged Port(s)
Configured ......................... 2,8-12
Actual ............................. 2,8-12
Tagged Port(s) ....................... 24
VLAN Name ............................ Engineering
VLAN ID .............................. 5
Protected Ports ...................... No
Untagged Port(s)
Configured ......................... 5-7
Actual ............................. 5-7
Tagged Port(s) ....................... 24
