AT-S62 Management Software Command Line Interface User’s Guide
Section II: Advanced Operations
253
An example of the event log is shown in Figure 23. The example uses
the full display mode.
Figure 23. Event Log Example
The columns in the log are described below:
S (Severity) - The event’s severity. Refer to Table 9 on page 253.
Date/Time - The date and time the event occurred.
Event - The module within the AT-S62 software that generated the
event followed by a brief description of the event. For a list of the
AT-S62 modules, see Table 8 on page 251.
Event ID - A unique number that identifies the event. (Displayed only in
the full display mode.)
Filename and Line Number - The subsection of the AT-S62 module
and the line number that generated the event. (Displayed only in the
full display mode.)
Table 9. Event Log Severity Levels
Value
Severity Level
Description
E
Error
Switch operation is severely impaired.
W
Warning
An issue may require manager attention.
I
Informational
Useful information that can be ignored
during normal operation.
D
Debug
Messages intended for technical support
and software development.
S Date
Time
EventID
Source File:Line Number
Event
------------------------------------------------------------------
I 2/01/04
09:11:02
073001
garpmain.c:259
garp: GARP initialized
I 2/01/04
09:55:15
083001
portconfig.c:961
pcfg: PortConfig initialized
I 2/01/04
10:22:11
063001
vlanapp.c:444
vlan: VLAN initialization succeeded
I 2/01/04
12:24:12
093001
mirrorapp.c:158
pmirr: Mirror initialization succeeded
I 2/01/04
12:47:08
043016
macapp.c:1431
mac: Delete Dynamic MAC by Port[2] succeeded
