Chapter 8: MAC Address Table Commands
164
Section I: Basic Operations
Figure 15 is an example of the information displayed by this command for
unicast addresses.
Figure 15. SHOW SWITCH FDB Command - Unicast Addresses
Note
The first address in the unicast MAC address table is the address of
the switch.
The columns are defined here:
VLAN - The ID number of the VLAN where the port is an untagged
member.
ADDRESS - The dynamic or static unicast MAC address learned on or
assigned to the port.
PORT - The port where the address was learned or assigned. The
MAC address with port 0 is the address of the switch.
STATUS - The type of address: static or dynamic.
Figure 16 is an example of a multicast address.
Figure 16. SHOW SWITCH FDB Command - Multicast Addresses
The columns are defined here:
MAC Address - The static or dynamic unicast MAC address.
VLAN ID - The ID number of the VLAN where the port is an untagged
member.
Switch Forwarding Database
Total Number of FDB Addresses: 121
VLAN ADDRESS
PORT
STATUS
------------------------------------------------------------
0
01:80:C1:00:02:01
0
Static (fixed, non-aging)
1
00:a0:d2:18:1a:c8
1
Dynamic
1
00:a0:c4:16:3b:80
2
Dynamic
1
00:a0:12:c2:10:c6
3
Dynamic
1
00:a0:c2:09:10:d8
4
Dynamic
1
00:a0:33:43:a1:87
4
Dynamic
1
00:a0:12:a7:14:68
4
Dynamic
1
00:a0:d2:22:15:10
4
Dynamic
1
00:a0:d4:18:a6:89
4
Dynamic
Multicast Switch Forwarding Database
Total Number of MCAST MAC Addresses: 1
MAC Address
VLANID Type
Port Maps (U:Untagged T:Tagged)
----------------------------------------------------------------
01:00:51:00:00:01
1
Static
U:1-4
T:
