Chapter 14: Event Log and Syslog Server Commands
236 Section II: Advanced Operations
For example, the setting of DEFAULT assigns port mirroring events a
code of 22 and encryption key events a code of 4.
Another option is to assign all events from a switch the same numerical
code using the LOCAL1 to LOCAL2 options. Each option represents a
predefined RFC 3164 numerical code. The code mappings are listed in
Table 7.
Table 6. Default Syslog Facilities
Facility
Number
Syslog Protocol
Definition
Mapped Event Log Modules and
Events
4 Security/
authorization
messages Security and authorization
messages from the following
modules: DOS, ENCO, PACCESS
(802.1x), PKI, PSEC (port security),
RADIUS, SSH, SSL, TACACS+,
and system events such as user
login and logout.
9 Clock daemon Time-based activities and events
from the following modules: TIME,
SNTP, and RTC.
16 Local use 0 All other modules and events.
22 Local use 6 Physical interface and data link
events from the following modules:
PCFG (port configuration), PMIRR
(port mirroring), PTRUNK (port
trunking), STP, and VLANs.
23 Local use 7 System events related to major
exceptions.
Table 7. Numerical Code and Facility Level Mappings
Numerical
Code
Facility Level Setting
17 LOCAL1
18 LOCAL2
19 LOCAL3
20 LOCAL4
21 LOCAL5
22 LOCAL6
