AlliedView™-EMS 3.11 Device Management Guide

Page 9 of 402

Basic Operations

Device Manager's main window shows the main panel of the target device. It has both

common and device-specific menus on its menu bar.

Note

- SNMPv3: All device-specific menu options are displayed regardless of the user's view

access security settings.

You can perform operations on the agent by doing a right click on the main panel or by

selecting a menu item from the menu bar. Ports and LEDs on the main panel indicate the
status of the port, system and traffic.

Topics:

Common operations on the main window

Menu for stacked devices

Port selection dialog box

Port status colors

LED status

Utilization

Common operations on the main window

Right clicking on a port
