AlliedView™-EMS 3.11 Device Management Guide

Page 259 of 402

8-Port (RJ-45) 10BASE-T/100BASE-TX/1000BASE-T Gigabit Ethernet Line Card

24-Port (RJ-45) 10BASE-T/100BASE-TX/1000BASE-T Gigabit Ethernet Line Card

LED

State

Description

DUPLEX Green

Orange

The port is operating at full-duplex.

The port is operating at half-duplex.

AT-SB4441

8-Port 1000BASE-X GBIC Line Card

LED

State

Description

DUPLEX

Green

The port is operating at full-duplex.

AT-SB4442

24-port 1000Base-X (SFP) Line Card

Note

- There are no LEDs on this module.

AT-SB4451 / AT-SB4452 / AT-SB4461 / AT-SB4462
