AlliedView™-EMS 3.11 Device Management Guide Page 335 of 402
Device Manager LEDs for AT-MCF06 Family
LED State Description
NORM Green
Gray
The unit is not performing a link test.
The unit is performing a link test.
TEST Green
Gray
The unit is performing a link test.
The unit is not performing a link test.
Note - The current firmware version does not allow Device Manager to support the Reset
button.
Agent Menu
From the Agent Menu, you can view and edit the system information for the device, or log
into the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Note - Device Manager allows the user to enter more than the 50-character limit for
the System Contact, System Name, and System Location parameters. However,
doing so may result in any of the following :
• Anywhere from 1 to 12 characters may be truncated from the entered value.
• The firmware password may be overwritten if 255 characters are entered for
the System Location parameter. Once this happens, a firmware reload will be
required.
• The last 50 characters of the entered value may go into the System Contact
parameter if 255 characters are entered for the System Name parameter.
Note - Device Manager allows the user to enter multiple-word values for the System
Contact, System Name, and System Location parameters. NULL values are not
allowed.
Management Interface Info
Displays basic interface information for the management port including description,
type, physical address, speed and operation status.
Temperature Info
Displays the temperature of the device in celsius.
Power Info
Displays the status of the main and backup power supplies.
