Uplink Modules
This section describes the Uplink Modules that can be installed on a switch. If one of these
uplink modules is installed in an uplink bay of a switch, it will be displayed in the uplink bay
image of the device panel in the main window. The operations available for the main device
include the ports in any of these uplink modules.
AT-A1x
LED
State
Description
DUPLEX Green
Orange
The port is operating at full-duplex.
The port is operating at half-duplex.
AT-A16/AT-A17/AT-A19
Note
- This image is only used on devices whose firmware does not allow Device Manager
to differentiate the AT-A16, AT-A17 and AT-A19 uplink modules from each other.
