AlliedView™-EMS 3.11 Device Management Guide

Page 260 of 402

8-Port (SC) 1000BASE-SX Gigabit Ethernet Line Card

8-Port (MT-RJ) 1000BASE-SX Gigabit Ethernet Line Card

8-Port (SC) 1000BASE-LX Gigabit Ethernet Line Card

8-Port (MT-RJ) 1000BASE-LX Gigabit Ethernet Line Card

LED

State

Description

DUPLEX

Green

The port is operating at full-duplex.

AT-SB4541

1-port 10GBASE-R Line Card

LED

State

Description

XFP Green

Orange

Off

An XFP is installed and enabled.

An XFP is installed, but disabled.

No XFP is installed.

SwitchBlade Line Cards
