AlliedView™-EMS 3.11 Device Management Guide
Page 80 of 402
Device Manager LEDs for AT-8324SX
LED
State
Description
PWR
Green
The switch is receiving power.
RPS Green
Gray
Redundant power is ON.
Redundant power is OFF.
DUPLEX Gray
Orange
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
STACK
ID
Green
The switch's position in the switch stack.
Note
- When multiple units of AT-8324SX are stacked together, port numbering is
continuous. This means that the first unit on the stack will have ports numbered from 1 to
32. The second unit on the stack will have ports numbered from 33 to 64. The third unit
will have ports numbered from 65 to 96 and the fourth unit from 97 to 128. It is assumed
that the maximum number of ports per unit is 32, 24 fixed ports plus up to 8 uplink ports.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log
into the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Note
- Device Manager allows the user to enter up to 255 characters for the System
Contact, System Name, and System Location parameters.
TFTP Download Management
Displays TFTP information.
Note
- Device Manager allows the user to enter up to 80 characters for the TFTP
File Name parameter but truncates it to 47 characters.
Note
- Device Manager does not allow the user to set the Download Mode
parameter to 'temporary'. Attempting to do so will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."
Reset
Displays the reset table that allows you to configure reset parameters before
restarting the management agent.
