AlliedView™-EMS 3.11 Device Management Guide

Page 72 of 402

AT-8324

Supports up to 8 stacked AT-8324 switches.

Device Manager LEDs for AT-8324

LED

State

Description

PWR

Green

The switch is receiving power.

DUPLEX Green

Orange

The port is operating in full-duplex mode.

The port is operating in half-duplex mode.

Note

- Please refer to

Uplink Modules

for the operations and behaviour of the expansion

modules installed on this device.

Note

- The current firmware version does not allow Device Manager to support the RPS

and MASTER LEDs.
