AlliedView™-EMS 3.11 Device Management Guide Page 70 of 402
Expansion Module Notes
• When the Port Speed and Mode parameter of an AT-A14 expansion module port is
set to 'auto sense' and the port is connected to a 100Mbps full duplex port on
another device, its corresponding Duplex LED on the device image turns orange
instead of green.
• The current firmware version does not allow the Port Speed and Mode parameter
of the AT-A14 expansion module port to be set to any value other than 'auto-sense'.
• A GBIC image is always visible on the GBIC slot of the AT-A15 expansion module
image even if there is no GBIC physically present in the slot.
• The Port Speed and Mode parameter of an AT-A15 expansion module port must
match the duplex mode of the port to which it is connected in order to establish
connection.
• The current firmware version does not allow Device Manager to distinguish the AT-
A16, AT-A17, and AT-A19 expansion modules from each other. With the connector
type (VF-45, SC, MT-RJ) being the only difference among them, all three expansion
modules have been made to share the same GIF image.
• Attempting to configure the Port Speed and Mode parameter of an AT-A16/AT-
A17/AT-A19 expansion module port to '10Mbps half-duplex' or '10Mbps full-duplex'
will automatically set it to '100Mbps half-duplex' or '100Mbps full-duplex'
respectively.
• The current firmware version does not allow the Port Speed and Mode parameter
of the AT-A17 expansion module ports to be set to 'auto sense'.
• When the Port Speed and Mode parameter of an AT-A18 expansion module port is
set to 'auto sense' and the port is connected to a full duplex port on another device,
its corresponding Duplex LED on the device image turns orange instead of green.
AT-8200XL Series
