AlliedView™-EMS 3.11 Device Management Guide

Page 310 of 402

Device Manager LEDs for the AT-x900-24X Series

LED

State

Description

PWR 1 and

PWR 2

Green

Gray

There is a power supply unit (PSU) in the PSU bay.

There is no power supply unit (PSU) in the PSU bay.

FAN Green

Gray

There is a functioning Fan Only Module (FOM) in the PSU bay.

There is no functioning Fan Only Module (FOM) in the PSU bay.

DUPLEX Green

Orange

The port is operating at full duplex.

The port is operating at half duplex.

Note

- Please refer to

Uplink Modules

for the operations and behavior of the Expansion

Modules installed on these devices.

Note

- The PWR LEDs do not reflect the operating state of the power supplies installed.

The PWR LEDs simply indicate the presence or absence of power supplies in the rear of

the chassis.

Note

- The FAN LED does not reflect the operating state of the FAN module installed. The

FAN LED simply indicates the presence or absence of a FAN module in the rear of the

chassis.

Note

- If only one expansion module is installed and it is installed on the right bay of the

device, the expansion module image will appear on the left bay of the device image.

Agent Menu

From the Agent menu, you can view and edit the system information for the switch, or log
into the CLI using Telnet.

System Info

Standard

Displays basic system information, including system name, location, contact and

description.


Enterprise

CPU Utilization

Displays information about the CPU utilization over different periods of time.

Fan Speeds

Displays information about fans installed in the device that have their fan speeds

monitored by environment monitoring hardware.
