W a t l o w S e r i e s P D ■ 97 ■ C h a p t e r 9 D e v i c e C o n f i g T a b l e
Parameter Name
and Description
Web Page Your
Settings
Range Default Modbus*
(Read/write and
scaling)
Output 3 - V Low ScaleSet unit value for low end of voltage range. This setting determines range of output.,Configuration Output 3,,0 to
10000,0,484-485 (R/W) (/1000)
Output 3 - V High ScaleSet unit value for high end of voltage range. This setting determines range of output.,Configuration Output 3,,0 to
10000,10000,486-487 (R/W) (/1000)
Output 3 - Low Process ScaleSet unit value for low power scale.This setting is the process power value when the analog output is at mini-
mum.,Configuration Output 3,,0 to 10000,0,488-489 (R/W) (/100)
Output 3 - High Process ScaleSet unit value for high power scale.This setting is the process power value when the analog output is at max-
imum.,Configuration Output 3,,0 to 10000,10000,490-491 (R/W) (/100) Output 3 - Voltage Low Scale
Set unit value for low end of
voltage range. This setting
determines range of output.
Configuration Output 3 0 to 10000 units 0 484-485 (R/W)
(/1000)
Output 3 - Voltage High Scale
Set unit value for high end of
voltage range. This setting
determines range of output.
Configuration Output 3 0 to 10000 units 10000 486-487 (R/W)
(/1000)
Output 3 - Retransmit Source
Select which source Output 3
will retransmit.
Configuration Output 3 Process Value 1 (0)
Process Value 2 (2)
Set Point 1 (1)
Set Point 2 (3) Process Value
1 (0) 492 (R/W)
Output 3 - Retransmit
Low Scale
Set low end of the current or
voltage range for the retrans-
mit signal.
Configuration Output 3 -2000000200 to 2000000200
degrees or units -2000000200 493-494 (R/W)
(/1000)
Output 3 - Retransmit
High Scale
Set high end of the current or
voltage range for the retrans-
mit signal.
Configuration Output 3 -2000000200 to 2000000200
degrees or units 2000000200 495-496 (R/W)
(/1000)
Output 3 - Retransmit Offset
Set the offset value for the re-
transmit signal.
Configuration Output 3 -9999000 to 9999000 de-
grees or units 0 497-498 (R/W)
(/1000)
Output 3 - State
Display state of output.
Monitor Device Inactive (0)
Active (1) Inactive (0) 467 (R)
