Watlow Series PD - Manual (Page 182)

Name and Description Web Page Range (Scaling) Iterations Default EIP Decimal (Hex) Modbus EIP Data Type Access
Current Transformer Measurement Input
Select which current transformer input value this
alarm will monitor.
Alarm {1 to 8}
Configuration
Off (0)
CT Input 3 (2)
CT Input 4 (3)
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
CT Input 4 (3)
105/1/4 (69/1/4)
105/2/4 (69/2/4)
105/3/4 (69/3/4)
105/4/4 (69/4/4)
105/5/4 (69/5/4)
105/6/4 (69/6/4)
105/7/4 (69/7/4)
105/8/4 (69/8/4) 534
548
562
576
590
604
618
632
UINT R/W
Current Transformer Alarm Set Point
Set the value that will trigger this alarm
Alarm {1 to 8}
Configuration
-30,000,000 to 30,000,000
(/1000)
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
0
101/1/50 (65/1/32)
101/1/56 (65/1/38)
101/1/62 (65/1/3E)
101/1/68 (65/1/44)
101/1/74 (65/1/4A)
101/1/80 (65/1/50)
101/1/86 (65/1/56)
101/1/92 (65/1/5C)
108-109
121-122
134-135
147-148
160-161
173-174
186-187
199-200
DINT R/W
Send Email
Select to enable an email to be sent on activation
of alarm 1.
Alarm {1 to 8}
Configuration
No (0)
Yes (1)
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
No (0) Web page only Web page only
Email Subject
Enter a subject for the alarm email.
Alarm {1 to 8}
Configuration
30 characters
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
0 Web page only Web page only
Alarm Hysteresis
Set how far the process value must return into the
normal operating range for an alarm to clear.
Alarm {1 to 8}
Configuration
0 to 30,000,000 (/1000)
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
3,000
105/1/8 (69/1/8)
105/2/8 (69/2/8)
105/3/8 (69/3/8)
105/4/8 (69/4/8)
105/5/8 (69/5/8)
105/6/8 (69/6/8)
105/7/8 (69/7/8)
105/8/8 (69/8/8) 539-540
553-554
567-568
581-582
595-596
609-610
623-624
637-638
DINT R/W
Latching
Select whether this alarm will be latched, which
requires that it be cleared manually after the
process value returns to the normal range.
Alarm {1 to 8}
Configuration
No (0)
Yes (1)
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
No (0)
105/1/7 (69/1/7)
105/2/7 (69/2/7)
105/3/7 (69/3/7)
105/4/7 (69/4/7)
105/5/7 (69/5/7)
105/6/7 (69/6/7)
105/7/7 (69/7/7)
105/8/7 (69/8/7) 538
552
566
580
594
608
622
636
UINT R/W
