W a t l o w S e r i e s P D
■
123
■
C h a p t e r 9 D e v i c e C o n f i g T a b l e
Parameter Name
and Description
Web Page Your
Settings
Range Default Modbus*
(Read/write and
scaling)
Hardware - Number of Possible Analog InputsDisplay total number of analog inputs available.,Device Information,,1 to 4,1, (R)
Hardware - Number of Possible Digital InputsDisplay total number of digital inputs available.,Device Information,,0 to 2,0, (R)
Hardware - Number of Possible OutputsDisplay total number of outputs available.,Device Information,,1 to 4,1, (R)
Hardware - Number of Analog Inputs ImplementedDisplay number of analog inputs implemented.,Device Information,,1 to 4,1,18 (R)
Hardware - Number of Outputs ImplementedDisplay number of outputs implemented.,Device Information,,1 to 4,1,20 (R)
Hardware - Date CodeIdentifies the manufacture date.,Device Information,,-2147483647 to 2147483647,0,9 (R)
Hardware - Serial NumberIdentifies the individual controllers’ serial number.,Device Information,,0 to 2000000200,0,7-8 (R)
Hardware - CJC Temperature 1Display the cold junction compensation temperature.,Device Information,,32000 to 167000,32000,1015-1016
(R) (/1000)
Hardware - CJC Temperature 2Display the cold junction compensation temperature.,Device Information,,32000 to 167000,32000,1019-1020
(R) (/1000)
Hardware - Number of Possi-
ble Analog Inputs
Display total number of
analog inputs available.
Device Information 1 to 4 1 (R)
Hardware - Number of Possi-
ble Digital Inputs
Display total number of digital
inputs available.
Device Information 0 to 2 0 (R)
Hardware - Number of Possi-
ble Outputs
Display total number of out-
puts available.
Device Information 1 to 4 1 (R)
Hardware - Number of Analog
Inputs Implemented
Display number of analog
inputs implemented.
Device Information 1 to 4 1 18 (R)
Hardware - Number of Out-
puts Implemented
Display number of outputs
implemented.
Device Information 1 to 4 1 20 (R)
Hardware - Date Code
Identifies the manufacture
date.
Device Information -2147483647 to 2147483647 0 9 (R)
Hardware - Serial Number
Identifies the individual
controllers’ serial number.
Device Information 0 to 2000000200 0 7-8 (R)
Hardware - CJC Temperature 1
Display the cold junction
compensation temperature.
Device Information 32000 to 167000 degrees 32000 1015-1016 (R)
(/1000)
Hardware - CJC Temperature 2
Display the cold junction
compensation temperature.
Device Information 32000 to 167000 degrees 32000 1019-1020 (R)
(/1000)
