W a t l o w S e r i e s P D

■

C h a p t e r 9 D e v i c e C o n f i g T a b l e

Device Configuration > Control Loops > Loop 2 > PID Set 5

Loop 2 - PID Set 5, Indirect Prop BandPID Set 5 - Set the heat (indirect) proportional band from set point in process units.,Configuration
Multiple PID Sets 2,,1000 to 999000,25000,863-864 (R/W) (/1000)
Loop 2 - PID Set 5, Indirect IntegralPID Set 5 - Set the heat (indirect) integral in minutes per repeat.,Configuration Multiple PID Sets 2,,0
to 99990,0,865-866 (R/W) (/1000)
Loop 2 - PID Set 5, Indirect DerivativePID Set 5 - Set the heat (indirect) derivative time in minutes.,Configuration Multiple PID Sets 2,,0 to
9990,0,867-868 (R/W) (/1000)
Loop 2 - PID Set 5, Indirect DeadbandPID Set 5 - Set the offset of the heat (indirect) proportional band from set point in process units.,Con-
figuration Multiple PID Sets 2,,0 to 999000,0,861-862 (R/W) (/1000)
Loop 2 - PID Set 5, Direct Prop BandPID Set 5 - Set the cool (direct) proportional band from set point in process units.,Configuration Multi-
ple PID Sets 2,,1000 to 999000,25000,871-872 (R/W) (/1000)
Loop 2 - PID Set 5, Direct IntegralPID Set 5 - Set the cool (direct) integral in minutes per repeat.,Configuration Multiple PID Sets 2,,0 to
99990,0,873-874 (R/W) (/1000)
Loop 2 - PID Set 5, Direct DerivativePID Set 5 - Set the cool (direct) derivative time in minutes.,Configuration Multiple PID Sets 2,,0 to
9990,0,875-876 (R/W) (/1000)
Loop 2 - PID Set 5, Direct DeadbandPID Set 5 - Set the offset of the cool (direct) proportional band from set point in process units.,Configu-
ration Multiple PID Sets 2,,0 to 999000,0,869-870 (R/W) (/1000)

Parameter Name

and Description

Web Page

Your

Settings

Range

Default

Modbus*

(Read/write and

scaling)

Loop 2 - PID Set 5 Indirect
Prop Band

Set the heat (indirect) propor-
tional band from set point in
process units.
