Name and Description
Web Page
Range (Scaling)
Iterations
Default
EIP Decimal (Hex)
Modbus
EIP Data Type
Access
Digital I/O State
Read and set the states of the digital I/O. 0 = off
and 1 = on. Bits 0 and 1 correspond to digital
inputs 1 and 2. Bits 8, 9, 10, and 11 correspond to
digital outputs 1, 2, 3, and 4. All other bits
reserved
Monitor Device
-32,768 to 32,767
0
101/1/95 (65/1/5F)
WORD
R/W
Device Configuration > Inputs > Analog Input {1 or 2}
Sensor Type
Set the sensor type.
Analog Input {1 or 2}
Configuration
None (0)
Thermocouple (1)
RTD (2)
Voltage Process (3)
Current Process (4)
INFOSENSE PnP (5)
Analog Input 1
Analog Input 2
None (0)
102/1/1 (66/1/1)
101/1/5 (65/2/1)
251
281
UINT
R/W
Thermocouple Parameters
Set the thermocouple type.
Analog Input {1 or 2}
Configuration
J (0)
K (1)
T (2)
E (3)
N (4)
C (5)
D (6)
PTII (7)
R (8)
S (9)
B (10)
Analog Input 1
Analog Input 2
J (0)
102/1/2 (66/1/2)
102/2/2 (66/2/2)
252
282
UINT
R/W
RTD Curve
Set the RTD linearization.
Analog Input {1 or 2}
Configuration
DIN 0.385 (0)
Analog Input 1
Analog Input 2
DIN 0.385 (0)
102/1/3 (66/1/3)
102/2/3 (66/2/3)
253
283
UINT
R/W
Process Precision
Indicates the number of decimal places displayed
on the web page for a process input. This can be
changed using the Series PD web page.
Analog Input {1 or 2}
Configuration
0 (0)
0.0 (1)
0.00 (2)
0.000 (3)
Analog Input 1
Analog Input 2
0 (0)
108/1/34 (6C/1/22)
108/1/38 (6C/1/26)
1108
1119
UINT
R
Process Units
Indicates the units for process type inputs
displayed in the web browser
Analog Input {1 or 2}
Configuration
Up to four alphanumeric
characters
Analog Input 1
Analog Input 2
108/1/36 (6C/1/24)
108/1/40 (6C/1/28)
1110-1111
1121-1122
SHORT_STRING
R
Low Process Scale
Set the value that will be displayed when the
analog input value is at its minimum, as
determined by the Low Voltage Scale or Low
Current Scale.
Analog Input {1 or 2}
Configuration
-30,000,000 to 30,000,000
(/1000)
Analog Input 1
Analog Input 2
-30,000,000
102/1/8 (66/1/8)
102/2/8 (66/2/8)
262-263
292-293
DINT
R/W
High Process Scale
Set the value that will be displayed when the
analog input value is at its maximum, as
determined by the High Voltage Scale or High
Current Scale.
Analog Input {1 or 2}
Configuration
-30,000,000 to 30,000,000
(/1000)
Analog Input 1
Analog Input 2
30,000,000
102/1/9 (66/1/9)
102/2/9 (66/2/9)
264-265
294-295
DINT
R/W
Low Voltage Scale
Set the input process voltage (in Volts) that will
correspond to the Low Process Scale.
Analog Input {1 or 2}
Configuration
0 to 10,000 (/1000)
Analog Input 1
Analog Input 2
0
102/1/6 (66/1/6)
102/2/6 (66/2/6)
258-259
288-289
DINT
R/W
High Voltage Scale
Set the input process voltage (in Volts) that will
correspond to the High Process Scale.
Analog Input {1 or 2}
Configuration
0 to 10,000 (/1000)
Analog Input 1
Analog Input 2
10000
102/1/7 (66/1/7)
102/2/7 (66/2/7)
260-261
290-291
DINT
R/W
Low Current Scale
Set the input process current (in milliamps) that will
correspond to the Low Process Scale.
Analog Input {1 or 2}
Configuration
0 to 20,000 (/1000)
Analog Input 1
Analog Input 2
4000
102/1/4 (66/1/4)
102/2/4 (66/2/4)
254-255
284-285
DINT
R/W
