Watlow Series PD - Manual (Page 157)

2.2.1 T
Æ O Static Assembly
If using the T
Æ O Static Assembly (Input) the following sizes should be defined in
RSLogix5000 for the following Comm Formats:
- DINT = 11
- INT = 22
2.2.2 T
Æ O Dynamic Assembly
Data Store Tag
Param
Type
EIP
Class
EIP
Instance
EIP
Attribute EIP - Data Type
tag_AI_ACTIVE_PROCESS_VALUE Numeric 101 1 3 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 101 1 8 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 101 1 13 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 101 1 18 DINT
tag_CLC_WORKING_SETPOINT Numeric 101 1 33 DINT
tag_CLC_WORKING_SETPOINT Numeric 101 1 41 DINT
tag_EIP_CL_POWER Numeric 101 1 96 INT
tag_EIP_CL_POWER Numeric 101 1 97 INT
tag_CL_METHOD Enumerated 101 1 34 UINT
tag_CL_METHOD Enumerated 101 1 42 UINT
tag_ EIP_DIO_STATE Numeric 101 1 95 WORD
tag_EIP_ALARM_STATUS Numeric 101 1 98 WORD
tag_AI_ERROR Enumerated 101 1 4 UINT
tag_AI_ERROR Enumerated 101 1 9 UINT
tag_AI_ERROR Enumerated 101 1 14 UINT
tag_AI_ERROR Enumerated 101 1 19 UINT
Data Store Tag
Param
Type
EIP
Class
EIP
Instance
EIP
Attribute
EIP Data
Type
tag_AI_ACTIVE_PROCESS_VALUE Numeric 100 1 3 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 100 1 8 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 100 1 13 DINT
tag_AI_ACTIVE_PROCESS_VALUE Numeric 100 1 18 DINT
tag_CLC_WORKING_SETPOINT Numeric 100 1 33 DINT
tag_CLC_WORKING_SETPOINT Numeric 100 1 41 DINT
tag_EIP_CL_POWER Numeric 100 1 96 INT
tag_EIP_CL_POWER Numeric 100 1 97 INT
tag_CL_METHOD Enumerated 100 1 34 UINT
tag_CL_METHOD Enumerated 100 1 42 UINT
tag_EIP_DIO_STATE Numeric 100 1 95 WORD
tag_EIP_ALARM_STATUS Numeric 100 1 98 WORD
tag_AI_ERROR Enumerated 100 1 4 UINT
tag_AI_ERROR Enumerated 100 1 9 UINT
tag_AI_ERROR Enumerated 100 1 14 UINT
tag_AI_ERROR Enumerated 100 1 19 UINT
155
*See Class, Instance, and Attribute Descriptions beginning on page 169 for enumerated values.
