Watlow Series PD - Manual (Page 175)

Name and Description Web Page Range (Scaling) Iterations Default EIP Decimal (Hex) Modbus EIP Data Type Access
Device Configuration > Inputs > Digital Input {3 or 4}
Function
Set the function for the digital input.
Digital Input {3 or 4}
Configuration
Off (0)
Acknowledge Alarm (1)
Switch To Manual Control
(2)
Switch Control Loop Off
(3)
Digital Setpoint (4)
Pause Data Logging (5)
Digital Input 3
Digital Input 4
Off (0)
103/1/1 (67/1/1)
103/2/1 (67/2/1) 351
371
UINT R/W
Active State
Select which state will activate the digital input
function.
Digital Input {3 or 4}
Configuration
False (0)
True (1)
Digital Input 3
Digital Input 4
False (0)
103/1/2 (67/1/2)
103/2/2 (67/2/2) 352
371
UINT R/W
Acknowlege Alarm: Alarm Action
Select what action will occur when the digital input
is used to acknowledge an alarm.
Digital Input {3 or 4}
Configuration
Silence Alarm (0)
Acknowledge Alarm (1)
Silence and Acknowledge
Alarm (2)
Digital Input 3
Digital Input 4
Silence Alarm (0)
103/1/17 (67/1/11)
103/2/17 (67/2/11) 368
388
UINT R/W
Acknowledge Alarm 1
Select to use the digital input to acknowledge
Alarm 1.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/3 (67/1/3)
103/2/3 (67/2/3) 353
373
UINT R/W
Acknowledge Alarm 2
Select to use the digital input to acknowledge
Alarm 2.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/4 (67/1/4)
103/2/4 (67/2/4) 354
374
UINT R/W
Acknowledge Alarm 3
Select to use the digital input to acknowledge
Alarm 3.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/5 (67/1/5)
103/2/5 (67/2/5) 355
375
UINT R/W
Acknowledge Alarm 4
Select to use the digital input to acknowledge
Alarm 4.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/6 (67/1/6)
103/2/6 (67/2/6) 356
376
UINT R/W
Acknowledge Alarm 5
Select to use the digital input to acknowledge
Alarm 5.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/7 (67/1/7)
103/2/7 (67/2/7) 357
377
UINT R/W
Acknowledge Alarm 6
Select to use the digital input to acknowledge
Alarm 6.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/8 (67/1/8)
103/2/8 (67/2/8) 358
378
UINT R/W
Acknowledge Alarm 7
Select to use the digital input to acknowledge
Alarm 7.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/9 (67/1/9)
103/2/9 (67/2/9) 359
379
UINT R/W
Acknowledge Alarm 8
Select to use the digital input to acknowledge
Alarm 8.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/10 (67/1/A)
103/2/10 (67/2/A) 360
380
UINT R/W
Switch To Manual Control Loop 1
Select to use digital input to switch Loop 1 to
manual control mode.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/11 (67/1/B)
103/2/11 (67/2/B) 361
381
UINT R/W
Switch To Manual Control Loop 2
Select to use the digital input to switch Loop 2 to
manual control mode.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/12 (67/1/C)
103/2/12 (67/2/C) 362
382
UINT R/W
Switch Control Loop 1 Off
Select to use the digital input to switch Loop 1 off.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/13 (67/1/D)
103/2/13 (67/2/D) 363
383
UINT R/W
Switch Control Loop 2 Off
Select to use the digital input to switch Loop 2 off.
Digital Input {3 or 4}
Configuration
No (0)
Yes (1)
Digital Input 3
Digital Input 4
No (0)
103/1/14 (67/1/E)
103/2/14 (67/2/E) 364
384
UINT R/W
Digital Set Point Loop
Select which loop's set point is affected by the
digital input.
Digital Input {3 or 4}
Configuration
Loop 1 (0)
Loop 2 (1) Digital Input 3
Digital Input 4
Loop 1 (0)
103/1/15 (67/1/F)
103/2/15 (67/2/F) 365
385
UINT R/W
