W a t l o w S e r i e s P D
■
56
■
C h a p t e r 7 C o n f i g u r a t i o n P a g e
Figure 56 — File Manager Web Page Tag Descriptions
Tag # File Manager Parameters Parameter Description
1. To Delete Check box to select files for deletion from on-board file storage.
2. File Name (datalog files) Displays datalog files currently in Series PD file storage, SD0. The
file name contains the date and time the datalog file was started.
The maximum file size is 190k bytes, with a maximum of 10 files.
3. Open Mode If column is blank, the datalog file is closed and can be opened or
deleted. If Create Append appears, data is being written to the file
and the file cannot be opened or deleted until the file is closed.
4. Delete Selected (Storage Device 0) Click this button to delete selected datalog files.
5. File Name Displays files currently in Series PD file storage, SD1. Use this
location to store any type of files. For example, system wiring dia-
grams, operating instructions, cascade style sheets, custom logos,
contact information, links to web sites, etc.
The maximum file size is 21k bytes, with a maximum of 10 files.
6. Navigation Frame Link Files with .htm or .html extensions create a link in the lower sec-
tion of the web page Naviagation Frame. Click on this link to open
the file in the browser window.
7. Delete Selected (Storage Device 1) Click this button to delete selected files.
8. Clear Entire File System Click this button to delete all datalog files.
9. Upload Files Send files to SD1 storage. Browse to select the file to load to the
Series PD and click Upload. A pop-up window indicates the file
transfer is in process and confirms the transfer is complete.
