Watlow Series PD User Manual
Page 180
Name and Description
Web Page
Range (Scaling)
Iterations
Default
EIP Decimal (Hex)
Modbus
EIP Data Type
Access
Retransmit: Source
Select the source the output will restransmit.
Output {1 to 4}
Configuration
Process Value 1 (0)
Process Value 2 (2)
Set Point 1 (1)
Set Point 2 (3)
Output 1
Output 3
Process Value 1
(0)
104/1/26 (68/1/1A)
104/3/26 (68/3/1A)
422
492
UINT
R/W
Retransmit: Low Scale
Set the value that corresponds to the low value of
the retransmit signal.
Output {1 to 4}
Configuration
-30,000,000 to 30,000,000
(/1000)
Output 1
Output 3
-30,000,000
104/1/27 (68/1/1B)
104/3/27 (68/3/1B)
423-424
493-494
DINT
R/W
Retransmit: High Scale
Set the value that corresponds to the high value of
the retransmit signal.
Output {1 to 4}
Configuration
-30,000,000 to 30,000,000
(/1000)
Output 1
Output 3
30,000,000
104/1/28 (68/1/1C)
104/3/28 (68/3/1C)
425-426
495-496
DINT
R/W
Retransmit: Offset
Set the offset value for the retransmit signal.
Output {1 to 4}
Configuration
-9,999,000 to 9,999,000
(/1000)
Output 1
Output 3
0
104/1/29 (68/1/1D)
104/3/29 (68/3/1D)
427-428
497-498
DINT
R/W
Output Source: Alarm 1
Enable Alarm 1 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/8 (68/1/8)
104/2/8 (68/2/8)
104/3/8 (68/3/8)
104/4/8 (68/4/8)
400
440
470
510
UINT
R/W
Output Source: Alarm 2
Enable Alarm 2 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/9 (68/1/9)
104/2/9 (68/2/9)
104/3/9 (68/3/9)
104/4/9 (68/4/9)
401
441
471
511
UINT
R/W
Output Source: Alarm 3
Enable Alarm 3 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/10 (68/1/A)
104/2/10 (68/2/A)
104/3/10 (68/3/A)
104/4/10 (68/4/A)
402
442
472
512
UINT
R/W
Output Source: Alarm 4
Enable Alarm 4 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/11 (68/1/B)
104/2/11 (68/2/B)
104/3/11 (68/3/B)
104/4/11 (68/4/B)
403
443
473
513
UINT
R/W
Output Source: Alarm 5
Enable Alarm 5 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/12 (68/1/C)
104/2/12 (68/2/C)
104/3/12 (68/3/C)
104/4/12 (68/4/C)
404
444
474
514
UINT
R/W
Output Source: Alarm 6
Enable Alarm 6 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/13 (68/1/D)
104/2/13 (68/2/D)
104/3/13 (68/3/D)
104/4/13 (68/4/D)
405
445
475
515
UINT
R/W
Output Source: Alarm 7
Enable Alarm 7 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/14 (68/1/E)
104/2/14 (68/2/E)
104/3/14 (68/3/E)
104/4/14 (68/4/E)
406
446
476
516
UINT
R/W
Output Source: Alarm 8
Enable Alarm 8 to trigger the output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/15 (68/1/F)
104/2/15 (68/2/F)
104/3/15 (68/3/F)
104/4/15 (68/4/F)
407
447
477
517
UINT
R/W
Output Source: Digital Input 3
Enable Digital Input 3 to trigger this output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/16 (68/1/10)
104/2/16 (68/2/10)
104/3/16 (68/3/10)
104/4/16 (68/4/10)
429
453
499
523
UINT
R/W
Output Source: Digital Input 4
Enable Digital Input 4 to trigger this output.
Output {1 to 4}
Configuration
No (0)
Yes (1)
Output 1
Output 2
Output 3
Output 4
No (0)
104/1/17 (68/1/11)
104/2/17 (68/2/11)
104/3/17 (68/3/11)
104/4/17 (68/4/11)
430
454
500
524
UINT
R/W
SERIES PD with EtherNet/IP
Addressing Information (rev c) 178
