Device Configuration > Outputs > Output 1

Output 1 - FunctionSelect the function of the output.,Configuration Output 1,,Off (0)Control (1)Event (2)Retransmit (3),Off (0),391 (R/W)
Output 1 - Output DirectionSelect whether the output will be for heating (reverse action) or cooling (direct action).,Configuration Output
1,,Off (0)Heat (Indirect) (1)Cool (Direct) (2),Off (0),398 (R/W)
Output 1 - Control SourceSet Loop which will control this output.,Configuration Output 1,,Loop 1 (0)Loop 2 (1),Loop 1 (0),393 (R/W)
Output 1 - Output Cycle TimeSet the cycle time in seconds.,Configuration Output 1,,,,392 (R/W) (/10)
Output 1 - Output Mode Time BaseSelect method of output control as either Fixed Time Base or Variable Time Base.,Configuration Output
1,,Fixed (0)Variable (1),Fixed (0),396 (R/W)
Output 1 - Low Power ScaleSet unit value for low power scale.This setting is the process power value when the analog output is at mini-
mum.,Configuration Output 1,,0 to 10000,0,418-419 (R/W) (/100)
Output 1 - High Power ScaleSet unit value for low power scale.This setting is the process power value when the analog output is at maxi-
mum.,Configuration Output 1,,0 to 10000,10000,420-421 (R/W) (/100)
Output 1 - Logic OperatorSelect logic operation for event output.,Configuration Output 1,,And (0)Or (1),And (0),399 (R/W)

Parameter Name

and Description

Web Page

Your

Settings

Range

Default

Modbus*

(Read/write and

scaling)

Output - System Power Line

Frequency

Select the frequency of the
line voltage.

Configuration Outputs

50 Hz. (0)
60 Hz. (1)

60 Hz. (1)

1075 (R/W)

Output 1 - Function

Select the function of the out-
put.

Configuration Output 1

Off (0)
Control (1)
Event (2)
Retransmit (3)

Off (0)

391 (R/W)

Output 1 - Output Direction

Select whether the output will
be for heating (reverse action)
or cooling (direct action).

Configuration Output 1

Off (0)
Heat (Indirect) (1)
Cool (Direct) (2)

Off (0)

398 (R/W)

Output 1 - Control Source

Set Loop which will control
this output.

Configuration Output 1

Loop 1 (0)
Loop 2 (1)

Loop 1 (0)

393 (R/W)

Output 1 - Output Cycle Time

Set the cycle time in seconds.

Configuration Output 1

0.1 to 60 seconds for non-
mechanical relay outputs
1.0 to 60 seconds for me-
chanical relay outputs

1.0 second for
non-mech
relay output
10.0 seconds
for mechanical
relay output

392 (R/W) (/10)

Output 1 - Output Mode

Time Base

Select method of output con-
trol as either Fixed Time Base
or Variable Time Base.

Configuration Output 1

Fixed (0)
Variable (1)

Fixed (0)

396 (R/W)

Output 1 - Low Power Scale

Set unit value for low power
scale. This setting is the
process power value when the
analog output is at minimum.

Configuration Output 1

0 to 10000 %
(two decimal places)

0

418-419 (R/W)
(/100)

Output 1 - High Power Scale

Set unit value for high power
scale. This setting is the
process power value when the
analog output is at maximum.

Configuration Output 1

0 to 10000 %
(two decimal places)

10000

420-421 (R/W)
(/100)

Output 1 - Logic Operator

Select logic operation for event
output.

Configuration Output 1

AND (0)
OR (1)

AND (0)

399 (R/W)
