Watlow Series PD User Manual
Page 178
Name and Description
Web Page
Range (Scaling)
Iterations
Default
EIP Decimal (Hex)
Modbus
EIP Data Type
Access
Heat (Indirect) Deadband
Set the offset of the heat (indirect) proportional
band from set point in process units.
Multiple PID Loop {1 or
2} Configuration
0 to 999,000 (/1000)
Loop 1 Set 1
Loop 1 Set 2
Loop 1 Set 3
Loop 1 Set 4
Loop 1 Set 5
Loop 2 Set 1
Loop 2 Set 2
Loop 2 Set 3
Loop 2 Set 4
Loop 2 Set 5
0
106/1/18 (6A/1/12)
106/1/26 (6A/1/1A)
106/1/34 (6A/1/22)
106/1/42 (6A/1/2A)
106/1/50 (6A/1/32)
106/2/18 (6A/2/12)
106/2/26 (6A/2/1A)
106/2/34 (6A/2/22)
106/2/42 (6A/2/2A)
106/2/50 (6A/2/32)
677-678
693-694
709-710
725-726
741-742
797-798
813-814
829-830
845-846
861-862
DINT
R/W
Cool (Direct) Propband
Set the cool (direct) proportional band in process
units.
Multiple PID Loop {1 or
2} Configuration
1,000 to 999,000 (/1000)
Loop 1 Set 1
Loop 1 Set 2
Loop 1 Set 3
Loop 1 Set 4
Loop 1 Set 5
Loop 2 Set 1
Loop 2 Set 2
Loop 2 Set 3
Loop 2 Set 4
Loop 2 Set 5
25,000
106/1/23 (6A/1/17)
106/1/31 (6A/1/1F)
106/1/39 (6A/1/27)
106/1/47 (6A/1/2F)
106/1/47 (6A/1/2F)
106/2/23 (6A/2/17)
106/2/31 (6A/2/1F)
106/2/39 (6A/2/27)
106/2/47 (6A/2/2F)
106/2/55 (6A/2/37)
687-688
703-704
719-720
735-736
751-752
807-808
823-824
839-840
855-856
871-872
DINT
R/W
Cool (Direct) Integral
Set the cool (direct) integral in minutes per repeat.
Multiple PID Loop {1 or
2} Configuration
0 to 99,990 (/1000)
Loop 1 Set 1
Loop 1 Set 2
Loop 1 Set 3
Loop 1 Set 4
Loop 1 Set 5
Loop 2 Set 1
Loop 2 Set 2
Loop 2 Set 3
Loop 2 Set 4
Loop 2 Set 5
0
106/1/24 (6A/1/18)
106/1/32 (6A/1/20)
106/1/40 (6A/1/28)
106/1/48 (6A/1/30)
106/1/56 (6A/1/38)
106/2/24 (6A/2/18)
106/2/32 (6A/2/20)
106/2/40 (6A/2/28)
106/2/48 (6A/2/30)
106/2/56 (6A/2/38)
689-690
705-706
721-722
737-738
753-754
809-810
825-826
841-842
857-858
873-874
DINT
R/W
Cool (Direct) Derivative
Set the cool (direct) derivative time in minutes.
Multiple PID Loop {1 or
2} Configuration
0 to 9,990 (/1000)
Loop 1 Set 1
Loop 1 Set 2
Loop 1 Set 3
Loop 1 Set 4
Loop 1 Set 5
Loop 2 Set 1
Loop 2 Set 2
Loop 2 Set 3
Loop 2 Set 4
Loop 2 Set 5
0
106/1/25 (6A/1/19)
106/1/33 (6A/1/21)
106/1/41 (6A/1/29)
106/1/49 (6A/1/31)
106/1/57 (6A/1/39)
106/2/25 (6A/2/19)
106/2/33 (6A/2/21)
106/2/41 (6A/2/29)
106/2/49 (6A/2/31)
106/2/57 (6A/2/39)
691-692
707-708
723-724
739-740
755-756
811-812
827-828
843-844
859-860
875-876
DINT
R/W
Cool (Direct) Deadband
Set the offset of the cool (direct) proportional band
from set point in process units.
Multiple PID Loop {1 or
2} Configuration
1,000 to 999,000 (/1000)
Loop 1 Set 1
Loop 1 Set 2
Loop 1 Set 3
Loop 1 Set 4
Loop 1 Set 5
Loop 2 Set 1
Loop 2 Set 2
Loop 2 Set 3
Loop 2 Set 4
Loop 2 Set 5
0
106/1/22 (6A/1/16)
106/1/30 (6A/1/1E)
106/1/38 (6A/1/26)
106/1/46 (6A/1/2E)
106/1/54 (6A/1/36)
106/2/22 (6A/2/16)
106/2/30 (6A/2/1E)
106/2/38 (6A/2/26)
106/2/46 (6A/2/2E)
106/2/54 (6A/2/36)
685-686
701-702
717-718
733-734
749-750
805-806
821-822
837-838
853-854
869-870
DINT
R/W
Cross Over Point 1
Set value to switch from PID set 1 to PID set 2.
Multiple PID Loop {1 or
2} Configuration
-30,000,000 to 30,000,000
(/1000)
Loop 1
Loop 2
30,000,000
106/1/14 (6A/1/E)
106/2/14 (6A/2/E)
669-670
789-790
DINT
R/W
Cross Over Point 2
Set value to switch from PID set 2 to PID set 3.
Multiple PID Loop {1 or
2} Configuration
-30,000,000 to 30,000,000
(/1000)
Loop 1
Loop 2
30,000,000
106/1/15 (6A/1/F)
106/2/15 (6A/2/F)
671-672
791-792
DINT
R/W
SERIES PD with EtherNet/IP
Addressing Information (rev c) 176
