W a t l o w S e r i e s P D

■

C h a p t e r 9 D e v i c e C o n f i g T a b l e

Device Configuration > Control Loops > Loop 1 > PID Set 1

Loop 1 - PID Crossover SourceSpecify to switch PID sets based on a set point or a process value.,Configuration Loop Settings 1,,Process Val-
ue (0)Set Point (1),Process Value (0),668 (R/W)
Loop 1 - PID Set 1, Indirect Prop BandPID Set 1 - Set the heat (indirect) proportional band from set point in process units.,Configuration
Loop Settings 1Configuration Multiple PID Sets 1,,1000 to 999000,25000,679-680 (R/W) (/1000)
Loop 1 - PID Set 1, Indirect IntegralPID Set 1 - Set the heat (indirect) integral in minutes per repeat.,Configuration Loop Settings 1Config-
uration Multiple PID Sets 1,,0 to 99990,0,681-682 (R/W) (/1000)
Loop 1 - PID Set 1, Indirect DerivativePID Set 1 - Set the heat (indirect) derivative time in minutes.,Configuration Loop Settings 1Configu-
ration Multiple PID Sets 1,,0 to 9990,0,683-684 (R/W) (/1000)
Loop 1 - PID Set 1, Indirect Dead BandPID Set 1 - Set the offset of the heat (indirect) proportional band from set point in process
units.,Configuration Loop Settings 1Configuration Multiple PID Sets 1,,0 to 999000,0,677-678 (R/W) (/1000)
Loop 1 - PID Set 1, Direct Prop BandPID Set 1 - Set the cool (direct) proportional band from set point in process units.,Configuration Loop
Settings 1Configuration Multiple PID Sets 1,,1000 to 999000,25000,687-688 (R/W) (/1000)
Loop 1 - PID Set 1, Direct IntegralPID Set 1 - Set the cool (direct) integral in minutes per repeat.,Configuration Loop Settings 1Configura-
tion Multiple PID Sets 1,,0 to 99990,0,689-690 (R/W) (/1000)
Loop 1 - PID Set 1, Direct DerivativePID Set 1 - Set the cool (direct) derivative time in minutes.,Configuration Loop Settings 1Configura-
tion Multiple PID Sets 1,,0 to 9990,0,691-692 (R/W) (/1000)
Loop 1 - PID Set 1, Direct Dead BandPID Set 1 - Set the offset of the cool (direct) proportional band from set point in process units.,Config-
uration Loop Settings 1Configuration Multiple PID Sets 1,,0 to 999000,0,685-686 (R/W) (/1000)
Loop 1 - PID Set 1 Crossover PointSet crossover value to switch from PID Set 1 to PID Set 2.,Configuration Loop Settings 1,,-30000000 to
30000000,30000000,669-670 (R/W) (/1000)

Parameter Name

and Description

Web Page

Your

Settings

Range

Default

Modbus*

(Read/write and

scaling)

Loop 1 - PID Crossover Source

Specify to switch PID sets
based on a set point or a
process value.

Configuration Loop
Settings 1

Process Value (0)
Set Point (1)

Process Value
(0)

668 (R/W)

Loop 1 - PID Set 1 Indirect
Prop Band

Set the heat (indirect) propor-
tional band from set point in
process units.
