Chapter 5 Components
DME Designer Owner’s Manual 318
■ Edit Palette
The edit palette is automatically displayed whenever the user control editor/user module editor is
active in design mode. Whenever you move the user control editor/user module editor, the edit palette
moves together with it. When you turn OFF design mode, the palette disappears.
Commands for editing in the user control editor/user module editor are provided on the edit palette.
■ [Design Mode Off] Button
Turns OFF the design mode.
■ [Undo] Button/[Redo] Button
Used to undo/redo operations.
■ [Cut] Button/[Copy] Button
Cuts or copies the selected controls.
→ See “Cut/Copy/Paste Controls” on
page 329 .
■ [Paste] Button
Pastes cut or copied controls.
→ See “Cut/Copy/Paste Controls” on
page 329 .
■ Alignment of Controls
Aligns the positions of multiple controls.
[Align Left] Button
Aligns all selected controls with the left edge of the leftmost selected control.
[Align Right] Button
Aligns all selected controls with the right edge of the rightmost selected control.
[Align To Top] Button
Aligns all selected controls with the top edge of the uppermost selected control.
[Design Mode Off] Button
[Undo] Button
[Redo] Button
[Cut] Button
[Copy] Button
[Paste] Button
Control Alignment Grid Setting
[Align Left] Button
[Align Right] Button
[Align To Top] Button
[Align To Bottom] Button
[Align Horizontally] Button
[Align Vertically] Button
[Horizontal/Center Align] Button
[Vertical/Center Align] Button
[Picture] Button
[TEXT] Button
[Box] Button
[Ellipse] Button
[Frame] Button
[Line] Button
[Scene Recall Button]
Button
