Chapter 5 Components
DME Designer Owner’s Manual 311
User Control Editor/User Module Editor
User Control Editor
The user control function lets you lay out a set of component controls in the Configuration window or
User Module window, and create a control window with them. The controls in the user control editor
are linked to the controls for the original component. If the parameters are changed in the user control
editor, the parameters will change in the same way in the component editor. If parameters are
changed in the component editor, the controls in the user control window will also change in the same
way.
You can create a compact control window by only including controls for parameters that are used
frequently.
You can also lay out controls for multiple components, so that you can adjust parameters for them from
a single window.
There is also a [Library] button in the user control editor, which you can use to save parameters to the
library.
User controls are created by selecting [View] menu
→ [User Control] → [New User Control] in the
Main Panel window. Created user controls are displayed in the [View] menu
→ [User Control]
submenu. If you select one, a window will open for it. The controls which can be opened by the user
control editor are automatically set according to the user security settings of the currently logged in
user.
User Control Editor
Laid Out Controls
Edit Palette
Component Editor
Controls Laid Out
in the User Control
