Chapter 4 Designer

DME Designer Owner’s Manual

255

Design Window Shared Settings and Operations

Preferences

You can set the operating environment for the Designer window in the “Preferences” dialog box. This
dialog box is opened using the [Preferences] command in the Designer window [Tools] menu.

■ Graphics

Ports & Wires

Specifies wire color, thickness, and type for each port type.

• [Color]

Sets the default color for the port and wire.

• [Width]

Sets the default wire width from a range of 1 to 5.

• [Type]

Sets the port type.

NOTE

The initial color and thickness of the wires produced when drawing connections are specified here. The color and
thickness of drawn wires can be changed via the Wire Properties dialog box.
