Chapter 5 Components
DME Designer Owner’s Manual 307
■ Knob
Drag to adjust the parameter.
You can change the way knobs operate, using the [Component Editor] tab
→ [Knob Mode] setting
in the “Preferences” dialog box.
“Preferences” dialog box
→ "Component Editor" tab (
page 70 )
■ Slider
You can change the parameter by dragging the slider.
You can set the action that results from using the mouse on the scale area with [Component Editor]
tab
→ [Slider Mode] in the “Preferences” dialog box.
“Preferences” dialog box → “Component Editor” tab ( page 70 )
■ Buttons
There are several types of buttons.
• Switches between ON/OFF. When turned on, the button lights up. The color depends on the button’s
function.
• In button sets of this type, you can select one of several buttons. When you do all other buttons in the
set turn off.
NOTE
To make a finer setting, press the key while dragging the knob when [Knob Mode] is “Linear”.
If you click a knob while pressing the key, the setting will return to its default value.
NOTE
To make a finer setting, press the key while dragging the slider.
If you click a slider while pressing the key, the setting will return to its default value.
Scale
Slider
When turned ON When turned OFF
