TOUCH

Lock Touchscreen

: Touchscreen control is locked. To unlock, tap the screen and follow the on-screen

instructions.

Pinch to Magnify

: Move two (2) fingers apart or together to toggle Magnify. For more information, go to

Double Tap Right to Record

: Double-tap the right 25% of the video area on the LCD to toggle record.

Double Tap Left to AF

: Double-tap the left 25% of the video area on the LCD to start autofocus when compatible

lenses are used.

GENLOCK OFFSET

NOTE:

HD-SDI ports are only available on select DSMC2 expanders. For more information, go to

Offset the video of the HD-SDI out to align it with the genlock signal:

Negative offset

: Advances the video, so the video reaches the switcher earlier than it would otherwise.

Positive offset

: Delays the video, so the video reaches the switcher later than it would otherwise.
