AVID DNXHD AND AVID DNXHR INFORMATION
By default, the camera records all videos and stills in the REDCODE RAW file format (records R3D files). You also
have the option to record to Avid DNxHD and Avid DNxHR (records .mxf files). This section provides general
information about recording Avid DNxHD/HR with the camera:
NOTE:
If Look Around is enabled, the Look Around area is recorded in the Avid DNxHD/HR file.
NOTE:
Enabling Look Around effects the aspect ratio of the scaled file, regardless of the recorded area.
Selecting a Recording Frame Rate that is not supported by Avid DNxHD/HR causes the codec file to be sub-
sampled to half of the selected Recording Frame Rate.
The camera cannot record Avid DNxHD/HR when Pre-Record is enabled.
The camera can record Avid DNxHD/HR only when either of the following recording modes is enabled:
Continuous Record
Motion + Stills
If HDRX
®
is enabled, only the selected monitor track is recorded to the Avid DNxHD/HR file. For more information,
go to
RED recommends performing a Secure Format before recording Avid DNxHD/HR. For more information, see the
, available at
The .mxf files have the same metadata that is in the REDCODE RAW files. The metadata is per clip, and not per
frame. At this time, there is no tool for extracting that metadata from the .mxf files.
You can select any resolution. When recording Avid DNxHD/HR, the camera scales that format to the Resolution
(2K or 4K) selected in the Codec menu. The field of view is maintained in Avid DNxHD/HR; the image is not
cropped.
If recording 4K Avid DNxHD/HR and the Resolution is less than 4K, the image is scaled to 2K.
For more information about Avid DNxHD/HR, see the
site.
To record Avid DNxHD/HR, go to
"Select Record File Format" on page 133
AVID DNXHD AND AVID DNXHR DESCRIPTION
The table below describes each Avid DNxHD/HR codec.
NAME
CODEC ID
MAXIMUM BITS
COLOR
DNxHR HQX
1271
12 bit
YCbCr 4:2:2
DNxHR HQ
1272
8 bit
YCbCr 4:2:2
DNxHR SQ
1273
8 bit
YCbCr 4:2:2
DNxHR 444
1270
12 bit
RGB 4:4:4
DNxHD 444
1256
10 bit
RGB 4:4:4
DNxHD HQX
1235
10 bit
YCbCr 4:2:2
DNxHD HQ
1238
8 bit
YCbCr 4:2:2
DNxHD SQ
1237
8 bit
YCbCr 4:2:2
