DISPLAYS AND ELECTRONIC VIEWFINDERS
RED offers the following displays and electronic viewfinders (EVFs):
NOTE: RED offers multiple mounting solutions for each camera type.
ITEM RESOLUTION TILT 1 SWIVEL 1 PART NUMBER
DSMC2 RED Touch 7.0" LCD (Woven CF) 1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0018
DSMC2 RED Touch 7.0" LCD (Aluminum) 1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0024
DSMC2 RED Touch 4.7" LCD 1280 x 720 Total: 240°
Forward: 90°
Backward: 150°
No swivel 730-0019
RED Touch 5.0" LCD 2 800 x 400 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0008
RED Touch 7.0" LCD 2, 3 1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0007
RED Touch 9.0" LCD 2 1280 x 768 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0011
RED Pro LCD 7" 2 1024 x 600 No tilt No swivel 730-0009
RED Pro Touch 7.0" LCD 2 1920 × 1136 No tilt No swivel 730-0025
DSMC2 Touch 7.0" Ultra-Brite LCD 2, 4 1920 x 1200 No tilt No swivel 730-0026
DSMC2 Touch 7.0" Ultra-Brite LCD (Direct Mount) 4 1920 x 1200 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0028
DSMC2 RED EVF (OLED) 2 1920 x 1080 N/A N/A 730-0021
BOMB EVF ® (LCOS) 2 1280 x 784 N/A N/A 730-0004
BOMB EVF (OLED) 2 1280 x 1024 N/A N/A 730-0010
1. Approximate measurements.
2. Using this display with a DSMC2 camera requires a DSMC2 LCD/EVF Adaptor A, DSMC2 Tactical Top Plate, or DSMC2 Production Top Plate.
3. The RED Touch 7.0" LCD requires that your camera is on firmware v5.2.38 or later.
4. The DSMC2 Touch 7.0" Ultra-Brite LCD requires that your camera is on firmware v7.2 or later.
