DSMC2 TACTICAL TOP PLATE
Figure: DSMC2 Tactical Top Plate
# CONNECTOR CONNECTOR TYPE
DETAILS
1 START/STOP
Fischer 3-pin 102
2 MONITOR
16-Pin 1B LCD/EVF
connector
Custom digital video and power interconnection between the camera
and RED LCD/EVF;
Pinout not published
DSMC2 PRODUCTION TOP PLATE
Figure: DSMC2 Production Top Plate
# CONNECTOR CONNECTOR TYPE
DETAILS
1 START/STOP
Fischer 3-pin 102
2 MONITOR
16-Pin 1B LCD/EVF
connector
Custom digital video and power interconnection between the camera
and RED LCD/EVF;
Pinout not published
