CDL
NOTE: This menu is only available in IPP2 mode. For more information, go to "Image Pipeline" on page 81 .
American Society of Cinematographers Color Decision List (ASC CDL) controls are a standardized, camera-agnostic
way to adjust the look of your images. Color corrections made with a device can therefore be applied or modified by
other devices, even if such devices are from different manufacturers and use different standards.
Use the CDL menu to set up:
Slope
Power
Offset
Saturation
MANAGE CDLS
Use the CDLs menu to apply and import/export CDLs.
CDLs can be stored on the camera or transferred to SSD to be shared with other cameras. When exporting CDLs from
camera to an SSD, the CDLs are saved to a folder on the SSD called “cdls”. When importing CDLs from an SSD to
camera, the CDLs must be stored on the SSD in a folder called “cdls”.
Apply : Apply the selected CDL.
Create : Create a new CDL using the current settings.
Delete : Delete the selected CDL.
: Export selected CDL from camera to SSD.
All : Export all CDLs from camera to SSD.
: Import selected CDL from SSD to camera.
All : Import all CDLs from SSD to camera.
COLOR
NOTE: This menu is only available in Legacy mode. For more information, go to "Image Pipeline" on page 81 .
NOTE: Saturation is disabled on Monochrome cameras.
Saturation : Adjusts color saturation. Range is 0.0 (monochrome) to 4.0 (super color). Default is 1.0.
Contrast : Adjusts the overall contrast of the image. Range is –1.0 (flat) to 1.0 (max contrast). Default is 0.0.
Brightness : Adjusts brightness without crushing highlights. Available range is –10.0 to 10.0. Default is 0.0.
Exp Comp : Adjusts exposure compensation. Available range is –7.0 to 7.0. Default is 0.0.
GAIN
NOTE: This menu is only available in Legacy mode. For more information, go to "Image Pipeline" on page 81 .
Adjust the red channel, blue channel, and green channel individually. The range for each is 0.0 (none of the color) to
10.0, and the default for each is 1.0.
