Page 162
11-16
Frame 14 Installation
Power Wiring
To access the power terminals, you must first remove the protective screens
(on NEMA/UL Type 1 and Type 12 enclosures), air flow plate and
protective covers from the Inverter units. These steps are detailed below.
Removing the Protective
Covers from the Inverter
Units
Removing the Protective Screens
To access the components within the Power Structures, you must first
remove the protective screens from the Inverter units.
Task
Description
Remove the screws that secure the protective screens to the inverter units and
remove the screens.
A
A
