10-4 Frame 13 Installation
Figure 10.2 Enclosure Code H (NEMA/UL Type 12, IP54) and W (NEMA/UL Type 12,
IP54 w/Conformal Coat)
Table 10.B Frame 13 Dimensions for Enclosure Code H (NEMA/UL Type 12 - IP54) and
W (NEMA/UL Type 12, IP54 w/Conformal Coat)
F
65
5 3 5
H Ø
2 PLACE S
1 3
E
D
B
122 454
662
A
C
G
NEMA/UL
Type 12 Roof
Assembly
NEMA/UL
Type 12
External
Filters
Wire entry for this enclosure is
between two pieces of soft foam.
If the adjustable plate is slid back,
a gap develops between the foam
pieces. otherwise, the foam acts
as a loose gasket around the
wires.
Stationary metal front bottom plate
Two pieces of soft foam taped to adjacent metal plates
Overlapping metal bottom plate (slightly adjustable)
Stationary metal back bottom plate
Voltage Class Amps A B C D E F G H
400/480V AC
(540/650V DC) 1150
1412 (56) 478 (18.8) 678 (26.7)
1 @ 242 (9.5)
1 @ 213 (8.4) 2443.5
(104.5) max.
535 (21) 735 (29) 1264 (50)
1300
1600 (63) 678 (26.7) 678 (26.7) 2 @ 242 (9.5)
2443.5
(104.5)
735 (29) 735 (29) 1464 (58)
1450
600/690V AC
(810/932V DC) 920
1412 (56) 478 (18.8) 678 (26.7)
1 @ 242 (9.5)
1 @ 213 (8.4) 2443.5
(104.5) max.
535 (21) 735 (29) 1264 (50) 1030
1180
Dimensions are in millimeters and (inches).
