9-4 Frame 12 Installation
Figure 9.4 Enclosure Code B (NEMA/UL Type 1, IP21) and K (NEMA/UL Type 1, IP21
w/Conformal Coat)
15. 88 (0.625) Di a . - 6 Mo u nting Hole s
Remove ab le Lifting Angle
Are a a v a il ab le for cond u it ro u ting
6 3 5
(25.0)
22 8 6
(90.0)
6 3 .5
(2.5)
295.5
(11.75)
295.5
(11.75)
19.0
(0.75)
54 8 .6
(21.6)
241. 3
(9.5)
50. 8
(2.0)
4 3 .2
(1.7)
5 33 .4
(21.0)
6 3 5
(25.0)
1270
(50.0)
Powerf u l Perform a nce, Flexi b le Control.
6 3 5
(25.0)
Powerf u l Perform a nce, Flexi b le Control.
Dimensions are in millimeters and (inches).
