5-6

Understanding IMC-S/23x Setups

Publication 999-122 - January 1997

Upload Inhibit

After entering the Applications Setup Menu, the IMC-S/23x asks:

If you desire to prevent the uploading of the Application Program
from memory, toggle to

YES

and press ENTER. This will prevent the

Application program from being viewed or uploaded.

Note:

If a hardware initialization is done with the keyswitch unlocked
and Upload Inhibit set to

YES

, the Application program will

be erased from the memory.

Editing the AxisLink
Configuration

For IMC-S/23x-L and IMC-S/23x-RL models only, after the correct
password has been entered, the IMC-S/23x asks

Toggle to

YES

and press ENTER to configure AxisLink for your

application.

Next the IMC-S/23x asks

Toggle to

YES

and press ENTER if you plan to use AxisLink in your

application. If you do not need to use AxisLink, toggle to

NO

and

press ENTER.

Editing the DH-485
Configuration

If the IMC-S/23x is configured for DH-485 communication (see
Configuring the IMC-S/23x in the Installation and Hookup section of
this manual), the motion controller next asks

Toggle to

YES

and press ENTER to configure the motion controller

for operation on the DH-485 network.

Inhibit Program Upload? NO

Edit AxisLink Config? NO

Edit AxisLink Config? YES

AxisLink? NO

Edit DH-485 Config? NO
