Understanding IMC-S/23x Setups

5-75

Publication 999-122 - January 1997

IMC-S/23x Application Setup Menu Reference (continued)

Prompt

Data

Edit Direct Command Mode Config?? NO/YES

Linefeed Insertion?? NO/YES
Carriage Return Insertion?? NO/YES
Duplex?? FULL/HALF
Multidrop?? NO/YES

B19
B20
B31
B33

Edit Operator Interface Config?? NO/YES

Operator Interface Serial Port?? A/B
DH-485 Communications Uses Port B:
Operator Interface Set to Port A!
Linefeed Insertion?? NO/YES
Carriage Return Insertion?? NO/YES
Application Password?

__________

Setup Password?

__________

D38

B21
B22

Edit Runtime Display Config?? NO/YES

Runtime Display?? NO/YES

Runtime Display Serial Port?? A/B
DH-485 Communications Uses Port B:
Runtime Display Disabled!
Display Refresh Time (Sec) =

__________

B23
D37

D39

Edit Serial Port Config?? NO/YES

Port A Baudrate?

300/1200/2400/4800/9600/
19200/38400/57600/115200/128000

Changing Baudrate . . .

Port B Baudrate?

300/1200/2400/4800/9600/
19200/38400/57600/115200/128000

Changing Baudrate . . .

D32

D33

Edit RIO Config?? NO/YES
RIO?? NO/ADAPTER
RIO Adapter Channel?? A/B
RIO Baud Rate?? 57.6KB/115.2KB/230.4KB
RIO Rack Size?? 1/4 / 1/2 / 3/4 / FULL
RIO Rack Address (0 - 31) =

__________

RIO Starting Group?? 0/2/4/6

B44-46
D57
D58
D56
D55
D59

Run App Program on Power-up?? NO/YES

B29
